UVA Spectral Response | 320-390 nm |
Suggested Operating Ranges | 10 Watt (UVA): 500 mW/cm2 to 10 W/cm2
|
Sample Rate/Smooth Mode | 2048 samples per second. The MicroCure reports the peak “Smooth Off” irradiance value versus the “RMS” or average irradiance value. |
Spatial Response | Approximately cosine |
Accuracy | +/- 7% typical @ 25°C, -0.2% per °C over operating range |
Operating Temperature Range | Range is 15-70°C |
Calibration | Each MicroCure is supplied with a NIST traceable calibration certificate |
Battery/Unit Life | Permanent lithium cell/200 readings or one year whichever comes first. Note: Expired MicroCure units can be return to EIT for proper disposal |
Timeout Period | 4 minutes nominal after last UV exposure or activation with UV exposure |
Dimensions/Weight | 1.3” x 0.95” x 0.25” (33 x 24.13 x 6.35 mm)/0.33 ounces (9.4 grams) |
Materials | Plated Aluminum/Nylon/ RoHS |
